Product Description
This compact, processing line can be used for used for continuously producing a number of hard candies under the most hygienic conditions. You can buy this system to not only produce quality candies, but also save manpower and space.
- Availability of PLC /computer process control;
- Operations are made easy with an LED touch panel;
- 300/450kgs/h is the standard production capacity;
- Stainless Steel is the primary material used for making the main parts
- Frequency inverters to control syrup masses flowing;
- Proportional liquid is added with in-line injection, dosing and pre-mixing techniques;
- Colors, flavors and acids are injected with dosing pumps;
- Automatic steam control system for stable steam supply to the microfilm cooker;
- Candies of two-color stripe depositing, twocolor double layers depositing, central filling, clear hard candies, etc.,. can be made.
- Based on the candies sample provided, we create our moulds.
Technical details:
| Model | CGD150S | CGD300S | CGD450 | CGD600S | CGD1200S |
| Output(kg/h) | 150 | 300 | 450 | 600 | 1200 |
| Candy weight | As per the candy size. |
| speed | 55~60 n/min | 55~60 n/min | 55~60 n/min | 55~60 n/min | 55~60 n/min |
| Steam consumption Steam pressure | 150kg/h, 0.5~0.8MPa | 300kg/h, 0.5~0.8MPa | 400kg/h, 0.5~0.8MPa | 500kg/h, 0.5~0.8MPa | 1000kg/h, 0.5~0.8MPa |
| Compressed air consumption Compressed air pressure | 0.2m3/min,0.4~0.6MPa | 0.2m3/min,0.4~0.6MPa | 0.2m3/min,0.4~0.6MPa | 0.2m3/min,0.4~0.6MPa | 0.2m3/min,0.4~0.6MPa |
| Electric power needed | 18kW/380V | 27kW/380V | 34kW/380V | 42kW/380V | 68kW/380V |
| Total length(m) | 17 | 17 | 17 | 17 | 19 |
Versatile and Precise ProductionCapable of handling various mould types and sizes, this depositing line delivers consistently precise candy molding for hard candies, lollipops, and filled varieties. PLC control and servo-driven mould movement improve accuracy and efficiency, guaranteeing uniformity in every batch produced.
Sophisticated Automation and ControlThis line boasts a fully automated process, from mixing and depositing to cooling and conveyance. The English-language operation panel, along with automatic lubrication and integrated cooling tunnel, allows for seamless operation and minimal manual intervention, maximizing productivity.
Robust Construction and Easy MaintenanceConstructed from food-grade stainless steel, the machine ensures hygienic operation and long-term durability. With an automatic lubricating system and clear operational controls, routine maintenance is simplified, minimizing downtime and prolonging equipment lifespan.
FAQs of Candy Lollipop Depositing Line:
Q: How does the Candy Lollipop Depositing Line improve candy production accuracy?
A: The line uses precise servo motor control and PLC-driven depositing mechanisms, achieving a depositing accuracy of 1.5 grams for each candy piece. This ensures consistent quality and uniformity across large production batches.
Q: What mould sizes and shapes are compatible with this depositing line?
A: The system accommodates a wide range of mould shapes and sizes, making it versatile for producing hard candies, lollipops, and filled candies to match diverse market preferences.
Q: When should industrial water and air compressor connections be supplied?
A: Industrial water (0.20.3 MPa) and the included air compressor (0.2 m/min) should be connected and operational before initiating production to ensure effective cooling, forming, and system function.
Q: Where should the machine be installed for optimal performance?
A: This machine, weighing 800 kg and measuring 9000 x 1300 x 2000 mm, is best installed in a commercial manufacturing facility with stable 380V electrical supply and adequate space for operation, maintenance access, and cooling ventilation.
Q: What is the process flow of this depositing line?
A: Raw materials are mixed and heated, then automatically deposited into moulds kept at a controlled temperature (110130C). The machine cools and shapes the candy, ejects finished products, and conveys them for packaging, all controlled via the PLC panel.
Q: How does the automatic lubrication system benefit production?
A: Automatic lubrication reduces mechanical wear, decreases maintenance downtime, and maintains smooth operation, which ultimately extends the machines longevity and ensures reliable candy forming.
Q: What after-sales support is provided for this equipment?
A: Engineers are available to service the machinery overseas. Additionally, standard export packaging and comprehensive user support ensure trouble-free installation and ongoing operation.
